Hadfield Steel Excavator Concrete Breaker Hammer 135mm 1852KG
Top Type Low Rate Of Chisel Breakage Hydraulic Breaker Hammer /
Excavator Jack Hammer 135mm
NTK breaker Top Type adopted advanced technology of oil pressure
control and fluid micro-adjust-ment makes stronger impact and its
persistence. Can enlarge the scope of demolition with long overall
length.
ALL the Breaker Set include:
Two Standard Chisel, One Tool Box, Two Pieline, One 4L Nitrogen Gas
Bottle
The detail for NTK1350 as blow
| TYPE | UNIT | NTK1350 | NTK1400 | NTK1550 | NTK1650 | NTK1750 |
| UNIT WEIGHT | KG | 1852 | 2081 | 2986 | 3248 | 4228 |
| LENGTH | mm | 2713 | 2824 | 3133 | 3577 | 3632 |
| Requierd Oil Flow | L/min | 120-180 | 120-180 | 180-240 | 200-260 | 210-290 |
| Working Pressure | kg/cm | 160-180 | 160-180 | 160-180 | 160-180 | 160-180 |
| Impact Rate | b.p.m | 350-500 | 350-500 | 300-450 | 280-370 | 150-300 |
| Hose Diameter | in. | 1 | 1 | 1¼ | 1¼ | 1¼ |
| Chisel Diameter | mm | φ135 | φ140 | φ155 | φ165 | φ175 |
| Chisel Length | mm | 1300 | 1300 | 1400 | 1500 | 1500 |
| Naise 85dB(A)-Distance | m | 16-22 | 16-22 | 26-35 | 37-42 | 38-45 |
| Applicable Excavator | m³TON | 0.7-0.8 | 0.7-0.9 | 1.1-1.4 | 1.3-1.5 | 1.4-2.0 |
| 18-21 | 18-26 | 28-35 | 38-45 | 40-55
|
Energy recovery valve
More than 90% energy recovery, making them the most efficient
breakers in their class!
Advanced blank firing protection as standard
Protect your investment! Piston movement is not interrupted, but
impact is prevented by a hydraulic brake. Saves time and money.
The right tool for the job
Choice of various tools for each type of application. Standard:
Moil point, pyramid, chisel or blunt tool Specials: Special tools
are available for dust extraction, super abrasive applications or
work in soft ground.
Fully variable automatic speed selection
Enabling the highest production in any application, these breakers
can select exactly the right amount of power to break through the
material, without wasting any energy.
NTK provides the construction industry with products utilizing the
latest in design innovation and quality. Our Hydraulic Breakers
have been proven and refined by many years of aggressive service,
backed by our industry leading warranty. FEATURES Available for 0.8
– 55 Ton machines Shock Absorbing Design Noise Reduction Technology
2 Year Factory Warranty Meets ISO 9001 Standards outsea Parts and
Service.
Design idea
We are a manufacturer with a professional design team and support
customization.
Low Price
The price is far below 40%~60% of the market price
Materials & Technology
Korean equipments and technology used to guarantee the quality.
Leading heat treatment technology.
100% ex-factory testing
Test parts, accessories and materials in strict accordance with
international standards
Pre-sales& after-sales service
On demand feedback
Online video instruction is available.
Provide reliable warranty certifications automatically for main
parts
Multiple uses
Widely used in gravel, mines, roads, demolition, metallurgy,
tunnels and other fields.
